Advantech 24″ Medical-Grade LCD Surgical Monitor, 350 Nits (PAX-324-C2B-NAS)
Deskripsi
| Category | Attribute | Value |
| Power | Consumption | 65 W max. |
| Power | Rating | DC 24 V, 4.16 A max. |
| Certifications | – | CE MDD 93/42/EEC (EN60601-1:2006; EN60601-1-2:2007), RoHS II |
| Environment | Humidity | Ta = 40 °C, 90% RH non-condensed/ |
| Environment | Pressure | Operational: 500 hPa to 1013 hPa / Storage: 500 hPa to 1013 hPa |
| Environment | Temperature | Operational: 0~40° C / Storage: -20~60° C |
| Input | DC Power Input DC Jack x 1 | DC 24 V, 4.16 A |
| Input | DP 1.2 Input DP Jack x 1 | DisplayPort 1.2, 1920 x 1200 @ 60 Hz max. |
| Input | DVI Input DVI Jack x 2 (Type D) | Digital RGB: TMDS, 1920 x 1200 @ 60 Hz max. |
| Input | HDMI 2.0 Input HDMI Jack x 1 (Type A) | Digital RGB: TMDS, 1920 x 1200 @ 60 Hz max. |
| Input | RS-232C D-Sub Jack x 1 | Service Port |
| Input | SDI1 Input BNC Jack x 1 | Serial Input Common Mode: 2.2 Vp-p (75 Ω); 1920 x 1080 @ 60 Hz max. |
| Input | S-Video Input Mini DIN Jack x 1 (4-pin) | Y: 1 Vp-p (75 Ω), C: 0.286 Vp-p (75 Ω) [NTSC] / Y: 1 Vp-p (75 Ω), C: 0.300 Vp-p (75 Ω) [PAL / SECAM] |
| Input | USB Up USB-B Jack x 1 | For Optional Touchscreen |
| Input | Video Input BNC Jack x 1 | 1 Vp-p (75 Ω) [NTSC / PAL / SECAM] |
| Output | DC Power Output DC Jack x 1 | DC 5 V or DC 12 V |
| Output | DVI Jack x 2 (Type D) | Digital RGB: TMDS, 1920 x 1200 @ 60 Hz max. |
| Output | SD/1 Output BNC Jack x 1 | Serial Input Common Mode: 2.2 Vp-p(75Ω); 1920 x 1080 @ 60 Hz max. |
| Output | S-Video Output Mini DIN Jack x 1 (4-pin) | Y: 1 Vp-p (75 Ω), C: 0.286 Vp-p (75 Ω) [NTSC] / Y: 1 Vp-p (75 Ω), C: 0.300 Vp-p (75 Ω) [PAL / SECAM] |
| Output | Video Output BNC Jack x 1 | 1 Vp-p (75 Ω) [NTSC / PAL / SECAM] |
| Physical Characteristics | Dimensions (W x D x H) | 578.13 x 68 x 402.78mm |
| Physical Characteristics | IP Ratings | Front IP65 / Top IPX1 |
| Physical Characteristics | VESA Mount | 100 x 100; 75 x 75 mm |
| Physical Characteristics | Weight | 7.2 kg |
| Accessories | – | Power Adapter |
| Warranty | – | 3 years |
| Optional Output | Audio Output | Audio Jack x 1 |
| Optional Output | SDI2 Output / BNC Jack x 1 | by request only |
| Optional Input | Audio Input | Audio Jack x 1 |
| Optional Input | AVAS NDcoder | – |
| Optional Input | RGB Input | D-sub x 1 |
| Optional Input | SDI2 Input / BNC Jack x 1 | by request only |
| LCD | Aspect Ratio | 16:10 |
| LCD | Color Depth | 8-bit 16.7M Colors / 10-bit 1.07B Colors |
| LCD | Contrast Ratio (Typ.) | 1000 : 1 |
| LCD | Display Mode | AH-IPS / AHVA |
| LCD | Native Luminance (Typ.) | 350 cd/m2 |
| LCD | Pixel Pitch | 0.270 x 0.270 mm |
| LCD | Resolution | 1920 x 1200 |
| LCD | Response Time | 14ms (G to G) / 14ms (Tr + Tf) |
| LCD | Screen Size | 24.1” (518.4 x 324.0 mm) |
| LCD | Touchscreen | – |
| LCD | Viewing Angle | 178°/ 178° |
